Limit Switch Kit for Boomerax XY Stage (One Axis)

From

340.00 CHF

Electrical limit switch for one axis of a Boomerax XY-stage.

Product Code	Boomerax XY Travel Range	Boomerax XY Base Flange	Price
UPGRADEMXY40(+MXLIMELKIT3)	±10 mm	DN40CF	CHF 340
UPGRADEMXY63(+MXLIMELKIT2)	±12.5 mm	DN63CF	CHF 340
UPGRADEMXY100XY12(+MXLIMELKIT2)	±12.5 mm	DN100CF	CHF 340
UPGRADEMXY100XY25(+MXLIMELKIT2)	±25 mm	DN100CF	CHF 340

Have questions about which solution works best for your application?
Connect with Ferrovac sales for expert advice.

A one-axis electrical limit switch kit designed to complement Boomerax XY Stage motorization kits by enhancing safety through travel restriction within the designated range.
It features two adjustable stop positions (expandable on request) and operates reliably in high-temperature environments, being fully bakeable up to 150°C.
Plugs and cables for custom wiring are not included.
- Designed for Boomerax XY-Stage motorization kits.
- Adjustable positions: Two (expandable on request)
- Switch type: Electrical limit switch
- Electronics operation: SPCO (Single Pole Changeover)
- Operating temperature: -40°C to +150°C
- Bakeability: Fully bakeable up to 150°C
- Wiring: Not included
