Sample Receivers

• Description

  The Ferrovac Drawer Style Receiver

  Ferrovac Drawer Style Receivers are very adaptable sample plate receivers for almost any application.

  They are compatible with all Ferrovac Flag Style Sample Plates, and there are various design adaptations available for specific applications, like cryogenic or high temperature sample preparation.

  Many standard drawer style receivers are available on the UHVstore online shop.


  UHV Store

  If the product catalogue does not include a receiver that fits your intended application, we'll gladly consider to working out a custom solution with you. Connect with Ferrovac Sales for expert advice.

  Contact

  ---

  Product Code:



  Viewing enlarged image:

  Sample Holder Type:

  The sample holder type describes which type of sample holder the receiver is compatible with.
  OM represents the standard, modernized Ferrovac design, which based on Omicron Flags.

  Options:

  Drawer style receivers are highly adaptable. The most commonly used options are listed here.

  • LT - Low / High Temperature: The receiver is adapted for very low or very high temperatures. Instead of upwards to reduce friction, the sample plate is pressed downwards onto a larger surface area to improve thermal conductivity with the receiver.
  • RA - Rear View Access: The receiver includes a large bore at the center to allow for optical access from below.
  • 3S - Three-Point Positioning: The receiver is adapted to enable precise three-point positioning of the sample plate. Comaptible only with the SHOM3S flag style plate.
  • EC13 - 13 Electrical Contacts: The receiver includes 13 electrical contacts, which the sample plate (only SHOMEC13 sample holders) connects to when inserted.
  • HTR - Heater Unit: The receiver is adapted to enable the direct mounting onto a sample heater (usually a PBN heating unit).

• Products

  •

    Drawer Style Receiver for Flag Style Plates

    RECOM

    From

    470.00 CHF
  •

    Three-Point Drawer Style Receiver for Flag Style Plates

    RECOM3S

    From

    990.00 CHF
  •

    Variable Temperature Drawer Style Receiver for Flag Style Plates

    RECOMLT(CBAU) | RECOMLT(MO)

    From

    1’150.00 CHF
  •

    Heater-Mountable Drawer Style Receiver for Flag Style Plates

    RECOMHTR1001S

    From

    1’600.00 CHF
  •

    Drawer Style Receiver with Rear Access for Flag Style Plates

    RECOMRA

    From

    1’500.00 CHF
  •

    Drawer Style Receiver for Flag Style Plates Holding 1 Inch Wafers

    RECUPS

    From

    1’860.00 CHF
  •

    Sample Plate Drawer with 13 Electrical Contacts

    RECOMEC13(ST) | RECOMEC13(CB)

    From

    4’250.00 CHF
  •

    Cryo Sample Plate Drawer with 13 Electrical Contacts

    RECOMCREC13V2

    From

    6’350.00 CHF
