Sample Storage Stacks

  • What is a Sample Storage Stack?

    The best and most commonlyused form of sample holder parking is the versatile sample storage stack. Perfect for sample parking or applications where transfering a high number of sample holders is necessary.

    These stacks can be configured for carrying multiple Ferrovac Flag Style Sample Plates and optimize the stack orientation to fit a wide range of transfer set-ups and sample sizes.

    The stack consists of modular drawer style receivers, that can be outfitted with spacers to fit the intended sample sizes.
    The minimum spacing allows for a sample height of 2mm. Additional spacers for higher samples can be specified in +1mm increments.

    Maximum sample height is <1.8mm + [height of the inserted spacer in millimeters].

    Receivers with different spacer sizes can be combined on the same stack.
    You can find more detail on how to build a stack with different spacer sizes in the product code explanation below.

    If you need assistance in finding the perfect solution for your application, connect with Ferrovac Sales for expert advice.

    Contact

    Product Code:

    The storage stack is highly customizable and modular.
    Here's an explanaiton on how to describe your intended solution with the Ferrovac product code.

    RECOMSTACKO(xxHyyS)K

    • O: Only if orthogonal access is required
    • xx: Number of slots
    • yy: height of additional spacer in mm
    • K: options: L = labelled / H = hanging (inverse)

    Viewing enlarged image:

    Configuration Examples:
    • RECOMSTACK(04H00S): 4x slots without spacers
    • RECOMSTACK(04H02S)L: 4x slots with 2mm spacers, labelled
    • RECOMSTACKO(03H00S)L: 3x slots without spacers, orthogonal access, labelled
    • RECOMSTACK(03H00S02H04S)H: 3x slots without spacers and 2x slots with 4mm spacers, inversely mounted
